KSB ServiceTool

The software package for your automation systems
KSB makes pump commissioning and parameterisation easier for our customers and service partners by offering a special automation software package.

KSB ServiceTool – easy to install and use

The KSB ServiceTool is composed of two software components: the PACTware frame application and the KSB device-specific Device Type Manager (DTM) drivers. For easy installation, we offer the KSB ServiceTool as a complete setup.
The following options are available for configuring and saving the device settings:
  • Device parameterisation
    • Saving the parameters on the PC
    • Transmitting parameters to the device
    • Editing parameters
    • Comparing parameter sets
  • Running device functions
  • Displaying process variables
  • Displaying alerts and warnings
  • Updating firmware


Advantages of the new version of the KSB ServiceTool

  • Automatic installation of all required software components
  • KSB Device Assistant to easily connect with every KSB device
  • Automatic COM port scan without prior user configuration via KSB Device Assistant
  • Notification about new updates
PW_Home
Screenshot of the update process in the KSB ServiceTool
The user-friendly KSB ServiceTool enables you to enter parameters without any prior knowledge.
The KSB ServiceTool makes it easier to analyse the pump control system.

Software and hardware requirements

  • Windows 10 and .NET Framework 4.8 are required for correct installation
  • To connect with the KSB device, a laptop, PC, tablet or other device with the relevant software is required.

Accessories and connection

To generate a connection between the device and the PC, the following connection hardware is required:

DeviceConnection hardwareKSB
materials numbers
  • Booster Control Advanced 1.5
  • Booster Control Advanced
  • Booster Control Basic
  • LevelControl Adv. 1 (mini-Compacta /
    Compacta)
  • LevelControl Adv.1
  • LevelControl Basic 2
  • PumpMeter
  • PumpDrive (1. Gen.)
USB - RS232 converter
&
serial service cable		01111255 &
47117698
  • Calio 3.0 DTM
  • Calio 800 DTM
USB - RS485 converter48014073
  • MyFlow-000K55-011K00
  • MyFlow-015K00-045K00
  • PumpDrive 2.0
  • PumpDrive 2.0 ECO
KSB Bluetooth gateway05326205
  • AmaRex Pro
Transmission module05274790
Parameterisation cable with USB connection05279586
For extended parameterisation rights a dongle is additionally needed.
Dongle service for authorisation:
accessory without software;
e-mail for enabling the dongle:
support.servicetool@ksb.com
Ident. number: 47121256
Schematic example of the connection between PC/tablet and the KSB device
The PC can be connected to the PumpDrive via Bluetooth using the external Bluetooth gateway (like a mobile terminal). If the PC does not have a Bluetooth interface, the connection can also be wired.
Connection can also be made by cable. To do this, use the USB charging cable of the external Bluetooth gateway.

Download PumpDrive R

For parameterisation of the PumpDrive R the Danfoss software “MCT 10 Basic” in the variant for application with the Danfoss FC 202 series can be used.
Release key (KSB-CD-Key): 12320200
The setup of the field bus modules of PumpDrive R is done with the corresponding files used for the Danfoss FC202 series:
Setup files field bus modules
