Pharmaceutical and Cosmetics Production
Beauty for your balance sheet: KSB hygienic pumps and valves for sterile processes
Cosmetics and pharmaceuticals manufacturing is subject to the most stringent hygiene and quality standards. KSB offers efficient and reliable solutions for every requirement.
Reliability and cost control are essential in pharmaceutical and cosmetics production
Manufacturing pharmaceutical and cosmetic products places extremely high demands on components – especially in terms of maintenance and cleaning.
In addition to application-specific requirements, products used in pharmaceutical and cosmetics production must also offer impressive cost effectiveness. The key here is avoiding costly unplanned downtimes.
KSB products for pharmaceutical and cosmetics production: reliable, flexible, durable
KSB offers a broad portfolio of reliable and low-maintenance pumps for sterile processes in hygienic design. This means that you will always find the right product for your needs at KSB.
Rely on outstanding KSB product quality, minimise unplanned downtime and lower your total cost of ownership.
You stand to benefit from KSB’s status as a full-range supplier specialising both in hygiene and secondary processes. In addition to pumps and valves for peripheral systems, KSB can also offer you a wide range of products for hygiene applications.
Highest product quality for the most exacting demands in the production of cosmetics and pharmaceuticals
The Vita pump range from KSB is the first choice for all hygiene and sterile processes in pharmaceutical and cosmetics production. With their design minimising dead volume, Vita pumps ensure absolutely sterile processes. The extensive Vita pump family offers the right product for every requirement.
KSB’s hygienic pumps are designed in line with the hygienic design requirements of EHEDG and EC regulation 1935/2004. No matter whether pumping, dosing or filling: Designs minimising dead volume ensure a longer shelf life of the end product and optimise the cleaning processes.
KSB’s pharmaceutical pumps are manufactured from absolutely hygienic, CIP/SIP-compatible materials. They are able to process, pump and dose fluids and highly viscous media especially gently – and thus fulfil a further quality criterion.
At KSB, a special LSA team (Life Sciences Applications) is on hand to help. The team has been trained for the requirements of the pharmaceuticals and cosmetics sector and has broad application knowledge.
Service-friendly volute casing pump with magnetless KSB SuPremE motor (exception: motor sizes 0.55 kW / 0.75 kW with 1500 rpm are designed with permanent magnets) of efficiency class IE4/IE5 and PumpDrive variable speed system. All wetted components are made of 1.4404/1.4409 (AISI 316L/CF3M) stainless steel. Designed with very little dead volume; open impeller, electropolished surface, excellent efficiency. Hygienic design for the highest requirements on cleanability (CIP/SIP-compatible), certified by the TNO Nutrition and Food Research Institute to EHEDG standards. All materials comply with FDA standards and EN 1935/2004. Trolley available among other accessories. ATEX-compliant version available.
Sturdy rotary lobe pump in hygienic design, bi-directional operation possible, horizontal or vertical orientation of connections. Hygienic design, excellent CIP/SIP compatibility due to its almost complete lack of dead volume or narrow clearances. All wetted components made of 1.4404/1.4409 (AISI 316L/CF3M) stainless steel; various rotor types, shaft seals and process connections available. Installed as a pump set with gear unit and standardised motor. Vitalobe is EHEDG-certified. The pump elastomers comply with the FDA standards and EN 1935/2004. Accessories include a trolley, a heatable casing or casing cover and a pressure relief arrangement. ATEX-compliant version available.
Diaphragm valve with butt weld ends or clamps; in straight-way, Y or T pattern, or as a multi-port valve; shut-off and sealing to atmosphere by confined and supported diaphragm. No dead volumes, suitable for sterilisation, SIP/CIP-compliant design, position indicator. All moving parts are separated from the fluid by the diaphragm. Maintenance-free.
