KSB submersible pump: Highest efficiency and non-clogging operation under the toughest of conditions

As one of the leading submersible pump manufacturers worldwide KSB is always there for you as a reliable partner, making sure to offer you the best possible energy efficiency and reliability.

As one of the leading submersible pump manufacturers worldwide KSB is always there for you as a reliable partner, making sure to offer you the best possible energy efficiency and reliability.

Highest flow rates and heads for grey water

Whether clear water or waste water: the areas of application for a submersible pump are diverse and involve different requirements. As one of the world's leading submersible pump manufacturers, KSB is always a reliable partner. We always pay attention to the greatest possible energy efficiency and safety. Whether for drainage in building services or for garden and outdoor use, e.g. for pumping seawater or saltwater: our submersible pumps impress with powerful results.

Benefits of a submersible pump by KSB

  • The right pump for every fluid thanks to corrosion-, impact- and abrasion-resistant materials
  • Particularly high operating reliability – triple shaft seal with barrier fluid reservoir prevents dry running. For Ama-Drainer N, for example, it also provides additional lubrication for the seal faces.
  • Absolutely tight with magnetic float switch with adjustable, variable level control and maximum travel stop
  • Optimum efficiencies by high-efficiency motors and variable hydraulic system
  • Low maintenance and cost-efficient operation by compact design

Our submersible pumps top seller

Fully floodable submersible motor pumps

AmaDrainer 4 / 5/AmaDrainer 80 / 100

AmaDrainer 4 / 5/AmaDrainer 80 / 100

AmaDrainer 4../5..: Vertical single-stage fully floodable submersible motor pump in close-coupled design, IP68, with or without level control, max. immersion depth: 7 m. AmaDrainer 80/100: Vertical single-stage fully floodable submersible motor pump in close-coupled design, IP68, with or without level control, max. immersion depth: 10 m.

AmaPorter

AmaPorter

Vertical single-stage submersible motor pump (grey cast iron) for waste water in close-coupled design for wet installation, stationary or transportable version.

Wet-installed submersible motor pumps and submersible pumps in discharge tube

Amacan K

Amacan K

Wet-installed submersible motor pump for installation in discharge tubes, with channel impeller, single-stage, single-entry. ATEX-compliant version available.

Amacan P

Amacan P

Wet-installed submersible motor pump for installation in discharge tubes, with axial propeller in ECB design, single-stage, single-entry. ATEX-compliant version available.

Amacan S

Amacan S

Wet-installed submersible motor pump for installation in discharge tubes, with mixed flow impeller, single-stage. ATEX-compliant version available.

Amaline

Amaline

Wet-installed horizontal propeller pump with submersible motor, equipped with direct drive or spur gear, ECB propeller with rigid, fibre-repellent blades, bolt-free connection to the discharge pipe. Explosion-proof version available.

Amarex

Amarex

Vertical single-stage submersible motor pump for wet installation, with vortex impeller (F-max) or open dual-vane impeller (D-max), stationary or transportable version. Single-stage, single-entry close-coupled pump sets which are not self-priming. ATEX-compliant version available.

Amarex KRT

Amarex KRT

Horizontal or vertical single-stage submersible motor pump in close-coupled design, with various next-generation impeller types, for wet or dry installation, stationary or transportable version, with energy-saving motor and models for use in potentially explosive atmospheres.

Amarex NS

Amarex NS

Vertical single-stage submersible motor pump for wet installation, with cutter (S), stationary or transportable version. Amarex N pumps are floodable, single-stage, single-entry close-coupled pump sets which are not self-priming. ATEX-compliant version available.

Submersible pumps. Short explained.

This is how submersible pumps work

Submersible pumps are placed or suspended directly in the fluid to be pumped. The fluid is drawn into the pump via the intake opening and then pumped upwards. This principle is used for many different applications.

Designed for wet installation with the motor submerged, submersible pumps are especially found in waste water engineering. They are located directly in the pump sump and are easy to install at different immersion depths using the corresponding lifting equipment and installation parts. KSB has developed pump casings and impellers that are especially suitable for waste water, bearing in mind that the fluid in waste water engineering is often heavily contaminated and contains solids.

Whatever the application, KSB has got the right impeller.

Strengths and applications of KSB submersible pumps

Submersible pumps can be used for a variety of fluids. Depending on their design, submersible motor pumps can be used for clear water and much more. Grey water pumps, for example, are able to pump sludge and grey water containing solids with a particle size of up to 35 millimetres.

In combination with explosion-proof motors and wear- and corrosion-resistant materials they are employed in municipal and industrial waste water disposal. The motors all meet the requirements of enclosure IP68. The compact design prevents major wear, keeps maintenance to a minimum and saves you cash, whether it is a submersible pump for a buried rainwater storage tank or for an industrial application.

Overview of submersible pump applications

  • Fighting floods
  • Drainage of pits, wells, yards and cellars
  • General drainage
  • Water disposal / treatment
  • Waste water transport
  • Water extraction from rivers and reservoirs, e.g. rainwater storage tanks above ground or buried
