Buoys limit the water protection zone in Lake Constance

Water Extraction

Clean drinking water worldwide – thanks to water extraction pumps from KSB.

Water is precious. Pumps from KSB are used to produce drinking water – by drawing water from wells or extracting surface water.

Energy and thus costs can be saved during water extraction

Install and forget: This is the wish of many plant operators. Submersible borehole pumps are installed deep in wells or shafts, making them difficult to access. They must therefore be virtually maintenance-free when it comes to water extraction and provide reliable operation for a very long time. However, since submersible motors require more energy than dry-installed motors, energy-efficient products are required to reduce the overall costs of the system.

Energy- efficient submersible motors from KSB can reduce your costs

Whether they extract surface water or pump groundwater from deep wells: Their design makes KSB’s submersible borehole pumps virtually maintenance-free and ensures a long service life. They often work for decades deep in wells and shafts. They also meet stringent hygiene standards – such as the French ACS drinking water regulation. The innovative UMA-S synchronous motors offer up to 14 % higher efficiencies in continuous operation. This keeps your operating costs as low as possible – while delivering the best possible performance.

In addition, KSB’s broad product portfolio offers you the right pump and valve for every application.

Pumps deliver outstanding performance – even under water

KSB is a full-liner for pumps, valves and service for water extraction applications with decades of experience and in-depth application knowledge. KSB offers you a comprehensive portfolio of dry-installed and wet-installed pumps and valves that are perfectly optimised to work with each other. All KSB products offer long-term efficiency and reliability and require minimal maintenance. This ensures the efficient, trouble-free operation of your system.

KSB application specialists will also advise you in all project phases to ensure that your system functions smoothly at all times. For example, we offer well pump measurements in which pumps remain installed when analysed. This allows potential savings to be quickly identified and implemented, reducing your energy costs and enabling you to achieve optimal system operation.

Our portfolio

KSB offers a wide range of products for water extraction

  • Axially split pumps
  • Vertical turbine pumps
  • Pressure boosting systems
  • Drainage- / waste water pumps
  • High-pressure pumps
  • Standardised pumps
  • Tubular casing pumps- / submersible pumps in discharge tubes
  • Volute casing pumps
  • Submersible motor pumps / submersible borehole pumps
  • Valves of various designs

Applications include

  • Water extraction from rivers, lakes and the sea
  • Groundwater extraction fromm wells and shafts
  • Rainwater harvesting
  • Drawdon of groundwater levels
  • Maintenance of groundwater levels

Your benefits

  • A broad portfolio featuring pumps and valves of different designs for all water extraction processes ensures you will find the product you need.
  • Expert advice for consultants, engineering contractors and operators thanks to extensive experience in numerous international projects
  • Optimised systems thanks to engineering services from a single source – including well pump measurements
  • Reduced energy consumption via submersible motors with high levels of efficiency
  • Improved system performance due to intelligent drive technology and variable speed systems
  • Optimised selection of pumps and matching valves with KSB Helps and KSB EasySelect
  • Reliable international supplier of pumps, valves and service – on the market for 150 years
  • Service and spare parts solutions covering the entire product life cycle complemented by 24-hour service from more than 3000 specialists in over 170 service centres worldwide

Find suitable pumps for water extraction

From submersible pumps to tubular casing pumps and submersible pumps in discharge tubes: KSB offers the right pumps and valves for all water extraction processes.

UPA 200 / UPA S 200

UPA 200 / UPA S 200

Single-stage or multistage single-entry centrifugal pump in ring-section design for vertical or horizontal installation. Optionally available with lift check valve or connection branch. For well diameters of 8 inches and above.



Multistage horizontal or vertical centrifugal pump in ring-section design, long-coupled or close-coupled, with axial or radial suction nozzle, cast radial impellers and motor-mounted variable speed system. ATEX-compliant version available.



Horizontal volute casing pump, single-stage, with ratings and main dimensions to EN 733, long-coupled, back pull-out design, with replaceable shaft sleeves / shaft protecting sleeves and casing wear rings, with motor-mounted variable speed system. With KSB SuPremE, a magnetless synchronous reluctance motor (exception: motor sizes 0.55 kW / 0.75 kW with 1500 rpm are designed with permanent magnets) of efficiency class IE4/IE5 to IEC TS 60034-30-2:2016, for operation on a KSB PumpDrive 2 or KSB PumpDrive 2 Eco variable speed system without rotor position sensors. Motor mounting points in accordance with EN 50347, envelope dimensions in accordance with DIN V 42673 (07-2011). ATEX-compliant version available.

Find suitable valves for water extraction now



Centred-disc butterfly valve with ISO 5211 compliant square shaft end, sealed by elastomer liner (EPDM XC / XU or nitrile K), with lever, manual gearbox, pneumatic or electric actuator; semi-lug body (T2), full-lug body (T4). Body types T2 and T4 are suitable for downstream dismantling and dead-end service. Valve disc made of nodular cast iron or stainless steel. Connections to EN.

ISORIA 20/25

ISORIA 20/25

Centred-disc butterfly valve with ISO 5211 compliant square shaft end, sealed by elastomer liner, with lever or manual gearbox, pneumatic, electric or hydraulic actuator. Semi-lug body (T2), full-lug body (T4) or U-section body with flat faces (T5). Body types T2, T4 and T5 are suitable for downstream dismantling and dead-end service with counterflange. Connections to EN, ASME, JIS.

Illustration of the phases of a product life cycle: Consultation and analysis, commissioning, operation and repair

Service at KSB SupremeServ means being fully looked after

KSB SupremeServ offers you a comprehensive range of services and spare parts for pumps, valves and other equipment – including for products from other manufacturers – from face-to-face consultation to installation, commissioning, maintenance and repair. More than 3500 specialists in over 190 service centres worldwide are available around the clock, seven days a week. Concentrate on your core business – and let us take care of the rest.

Inspection service

Inspection service

KSB’s inspection service provides regular pump inspection and pump maintenance to ensure the reliable operation and increased availability of your system.

  • Preventing failures
  • 24-hour on-call service
Reverse Engineering for pumps and valves

Reverse Engineering

Reverse engineering makes it possible to quickly reproduce pump spare parts that are hard to find or no longer available.

  • Straightforward reproduction of spare parts
  • The quality matches that of the original
KSB mechanical seals for pumps and valves

KSB Mechanical Seals

The mechanical seal is one of the most important components in any pump. KSB’s in-house shaft seals ensure that your system operates efficiently.

  • Longer service life
  • Reduced costs for maintenance and spare parts
