Eta keeps the world on the move.
KSB's Eta pumps keep the world on the move with unrivalled product and service diversity as standard. All pumps from the Eta family offer optimised hydraulic systems in an (almost) infinite number of variants.
The benefits of our Eta pumps speak for themselves.
Energy efficiency
- Outstanding hydraulic design, excellent efficiency
- Already meets the energy requirements of tomorrow
- Impellers trimmed as standard for pump operation at best efficiency point
- Maximum energy savings by variable speed operation with KSB PumpDrive in combination with high-efficiency KSB SuPremE® motors of efficiency class IE4 (in compliance with IEC/CD 60034-30 Ed. 2)
Versatility
- Great variety of materials for perfectly matching the pump to the fluid handled
- Comprehensive selection chart extended by additional sizes for small flow rates
- Motor options ranging from standard asynchronous motors to our high-efficiency IE4-compliant KSB SuPremE® motors (IE4 to IEC/CD 60034-30 Ed. 2): benefit from the optimum drive solution to match any application.
- Our PumpDrive, Hyamatic, and LevelControl automation options provide optimum control and monitoring functions for your pump system.
Find suitable products now
Etanorm/Etanorm MyFlow/Etanorm Pro
Single-stage volute casing pump in back pull-out design, with ratings and main dimensions to EN 733, with IEC-compatible power drive system comprising PumpDrive 2 and KSB SuPremE® motor or PumpDrive 3 (efficiency class IE4/IE5 to IEC TS 60034-2-3:2016) and motor-integrated frequency inverter. The pump is designed with replaceable casing wear rings, closed radial impeller with multiply curved vanes, single mechanical seal or double mechanical seals to EN 12756, shaft equipped with replaceable shaft protecting sleeve in the shaft seal area. The back pull-out design allows the coupling, bearing brackets and impeller to be dismantled without the need to disconnect the pump casing from the piping. Motor mounting points in accordance with IEC 60072, envelope dimensions in accordance with DIN V 42673 (07-2011). ATEX-compliant version available. Well ahead of the ErP Directive's efficiency requirements.
Etabloc/Etabloc Pro/Etabloc MyFlow
Single-stage volute casing pump in close-coupled design, with ratings to EN 733, with IEC-compatible power drive system comprising PumpDrive 2 and KSB SuPremE® motor or PumpDrive 3 (efficiency class IE4/IE5 to IEC TS 60034-2-3:2016) and motor-integrated frequency inverter. Shaft fitted with a replaceable shaft sleeve in the shaft seal area. Volute casing and casing cover with replaceable casing wear rings. Volute casing with integrally cast pump feet for variants B, C and S. Motor mounting points in accordance with IEC 60072, envelope dimensions in accordance with DIN V 42673 (07-2011). ATEX-compliant version available. Well ahead of the ErP Directive's efficiency requirements.
Etaline/Etaline Pro/Etaline MyFlow
Single-stage volute casing pump in in-line design with IEC-compatible power drive system comprising PumpDrive 2 and KSB SuPremE® motor or PumpDrive 3 (efficiency class IE4/IE5 to IEC TS 60034-2-3:2016) and motor-integrated frequency inverter. Pump shaft and motor shaft are rigidly connected; with uncooled mechanical seal to EN 12756 and replaceable casing wear rings. Drive lantern made of grey cast iron. Motor mounting points in accordance with IEC 60072, envelope dimensions in accordance with DIN V 42673 (07-2011). ATEX-compliant version available. Well ahead of the ErP Directive's efficiency requirements.
Etanorm SYT
Volute casing pump for horizontal installation, back pull-out design, single-stage, with ratings and dimensions to EN 733, radially split volute casing with integrally cast pump feet, replaceable casing wear rings, closed radial impeller with multiply curved vanes, single mechanical seal to EN 12756, double mechanical seal to EN 12756, drive-end bearings: rolling element bearings, pump-end bearings: plain bearings, with magnetless KSB SuPremE motor (exception: motor sizes 0.55 kW / 0.75 kW with 1500 rpm are designed with permanent magnets) of efficiency class IE4/IE5 and PumpDrive variable speed system; ATEX-compliant version available.
