KSB equips the largest waste water treatment plant in Asia with waste water pumps
The Bailonggang waste water treatment plant in Shanghai is the largest waste water treatment plant in Asia and one of the biggest in the world. It disposes of the waste water produced by around 3.6 million people.
The Bailonggang waste water treatment plant in Shanghai is the largest waste water treatment plant in Asia and one of the biggest in the world. It disposes of the waste water produced by around 3.6 million people.
The project:
Shanghai’s waste water treatment
The project saw the construction of one of the world’s largest waste water treatment plants in Bailonggang, in direct proximity to Shanghai, a metropolis with a population in the double-digit millions in Eastern China. The aim was for the plant to clean one third of all the waste water from a catchment area of over 270 km² – more than two million cubic metres every day.
The challenge:
One of the largest waste water treatment plants in Asia
What was special about this task was the sheer scale coupled with the high output requirements placed on the waste water equipment. For the construction of the waste water treatment plant, hundreds of waste water pumps were needed. The operating company opted for KSB as the supplier because KSB pumps fulfilled all of the performance parameters specified without exception. In particular the higher levels of hydraulic efficiency compared to many competitor products are today making a major contribution to the energy efficiency of the entire waste water treatment plant.
The solution:
Over 300 submersible pumps including all components
KSB supplied a total of 241 submersible waste water pumps from the Amacan range, 65 submersible motor pumps from the Amarex KRT and Amarex N ranges, six dry-installed SPN waste water pumps and six dry-installed ZL axial flow pumps. The pumps were supplied with all requisite components ready for connection, some already with the necessary control cabinets.
Today, the Bailonggang waste water treatment plant in Shanghai is the largest waste water treatment plant in Asia and one of the biggest in the world. One third of all the waste water produced by the city with a population in the double-digit millions is cleaned here. Every day, over two million cubic metres of waste water pass through the waste water treatment plant.
Data | Facts | Figures
Location: Shanghai, China
Application: Waste weater treatment
Used products:
241 Amacan submersible motor pumps
65 submersible motor pumps from the Amarex KRT and Amarex N ranges
6 dry-installed SPN waste water pumps
6 dry-installed ZL axial flow pumps
65 submersible motor pumps from the Amarex KRT and Amarex N ranges
6 dry-installed SPN waste water pumps
6 dry-installed ZL axial flow pumps
Used products
AmaCan P
Motobomba sumergible monoetapa con hélice axial de diseño ECB (Ever Clean Blades), de aspiración simple, para instalación completamente sumergida en pozo de tuberías. Disponible en versión ATEX.
Amarex KRT
Motobomba sumergible vertical u horizontal, monoetapa, monobloc, con diversos tipos de impulsores de nueva generación, de instalación húmeda o seca, versión estacionaria o transportable, con motor de alta eficiencia energética y disponible en versión con protección contra explosiones.
Amarex NS
Motobomba sumergible vertical monoetapa, de instalación húmeda, con impulsor dilacerador (S), impulsor vortex (F) o impulsor monoálabe diagonal (D) en versión estacionaria y transportable. Las bombas Amarex N son grupos monobloc inundables, monoetapa, de aspiración simple y no autoaspirantes. Disponible en versión ATEX.
