KSB pressure booster systems and pumps ensure a constant water supply pressure.

With a pressure booster system from KSB one or several pressure booster pumps are installed in a bypass line to the main water supply line and provide a constant water supply pressure.

With a pressure booster system from KSB one or several pressure booster pumps are installed in a bypass line to the main water supply line and provide a constant water supply pressure.

Keeping water pressure constant in higher buildings with pressure boosting systems

Whether in irrigation systems, residential buildings, office buildings or hospitals: If the normal pressure is not sufficient, the water pressure must be increased. A KSB booster system ensures constant water supply pressure by installing one or more booster pumps in a bypass line to the main line.

Benefits of pressure booster systems and pressure booster pumps by KSB

  • User-friendly straightforward menu navigation
  • Reliable operation with corrosion-resistant materials and designs
  • Ready-to-connect, supplied pre-set and tested for functionality
  • Very compact, space-saving design
  • Service-friendly easy accessibility

Our pressure booster pumps top seller

Pressure booster pumps

Comeo

Comeo

Multistage horizontal centrifugal pump in close-coupled design

Movitec

Movitec

Multistage vertical high-pressure centrifugal pump in ring-section design with suction and discharge nozzles of identical nominal diameters arranged opposite to each other (in-line design), close-coupled. With KSB SuPremE, a magnetless synchronous reluctance motor (exception: motor sizes 0.55 kW / 0.75 kW with 1500 rpm are designed with permanent magnets) of efficiency class IE4/IE5 to IEC TS 60034-30-2:2016, for operation on a KSB PumpDrive 2 or KSB PumpDrive 2 Eco variable speed system without rotor position sensors. Motor mounting points in accordance with EN 50347, envelope dimensions in accordance with DIN V 42673 (07-2011). ATEX-compliant version available.

Movitec H(S)I

Movitec H(S)I

Multistage horizontal high-pressure centrifugal pump with KSB SuPremE, a magnetless synchronous reluctance motor (exception: motor sizes 0.55 kW / 0.75 kW with 1500 rpm are designed with permanent magnets) of efficiency class IE4/IE5 to IEC TS 60034-30-2:2016, for operation on a KSB PumpDrive 2 or KSB PumpDrive 2 Eco variable speed system without rotor position sensors.

Fully automatic single-pump system

DeltaSolo

DeltaSolo

Fully automatic single-pump system available in two variable speed versions. The MVP and SVP variable speed versions ensure variable speed control of each pump by motor-mounted frequency inverter for asynchronous motors (MVP) or by PumpDrive variable speed system and KSB SuPremE motor (SVP), respectively, providing fully electronic control to ensure the required supply pressure.

DeltaSolo D

DeltaSolo D

Fully automatic package single-pump system with 8-litre membrane-type accumulator. The system is started and stopped as a function of pressure.

Fully automatic pressure booster system with one to two pressure booster pumps

DeltaCompact

DeltaCompact

Fully automatic ready-to-connect package single-pump pressure booster system / dual-pump pressure booster system with variable speed system

Fully automatic pressure booster system with two to four vertical high-pressure pumps

DeltaBasic

DeltaBasic

Fully automatic pressure booster system with two to three (MVP) / four (SVP) vertical high-pressure pumps in two variable speed versions. The MVP and SVP variable speed versions ensure variable speed control of each pump by motor-mounted frequency inverter for asynchronous motors (MVP) or by PumpDrive variable speed system and KSB SuPremE motor (SVP), respectively, providing fully electronic control to ensure the required supply pressure. Equipped with a central fuse box.

DeltaPrimo

DeltaPrimo

Fully automatic package pressure booster system with two to three (VC) / four (F/SVP) vertical high-pressure pumps; available in cascade-controlled and two variable speed designs. Cascade control (F) for ensuring the required supply pressure. The VC and SVP versions ensure variable speed control of each pump by cabinet-mounted frequency inverter (VC) or motor-mounted PumpDrive variable speed system and KSB SuPremE motor (SVP), respectively, providing fully electronic control to ensure the required supply pressure. Automated with KSB BoosterCommand Pro.

Fully automatic pressure booster system with two to six vertical high-pressure pumps

DeltaMacro

DeltaMacro

Fully automatic package pressure booster system with two to four (F) / six (VC/SVP) vertical high-pressure pumps; available in cascade-controlled and two variable speed designs. Cascade control (F) for ensuring the required supply pressure. The VC and SVP versions ensure variable speed control of each pump by cabinet-mounted frequency inverter (VC) or motor-mounted PumpDrive variable speed system and KSB SuPremE motor (SVP), respectively, providing fully electronic control to ensure the required supply pressure. Automated with KSB BoosterCommand Pro Plus.

Pressure booster systems. Short explained.

This is how pressure booster systems work

Pressure booster systems ensure a constant water supply pressure when the normal mains pressure is insufficient. In modern systems, this is done by one or several variable speed pressure booster pumps installed in a bypass line to the mains water supply line. In order to prevent any pumping in a closed circuit, a non-return valve is fitted in the main water supply pipe between the booster pumps' suction and discharge connections.

Strengths and applications of KSB pressure booster systems and pressure booster pumps

Pressure booster systems / pressure booster pumps by KSB are impressively compact and space-saving in design. They are energy-efficient and suitable for drinking water.

Overview of applications covered by pressure booster pumps and systems:

  • Residential buildings
  • Office buildings
  • Hotels
  • Department stores
  • Clinics / hospitals
  • Commercial and industrial plants
  • General irrigation / spray irrigation
  • Rainwater harvesting
  • Domestic water supply systems
