KSB high-pressure pumps: Top performance through technical innovation

With its many years of tradition and innovation, KSB offers products of the highest quality that are continuously being further developed, also in the sector of high-pressure pumps. Trust in the long tradition of our company and make use of our comprehensive service for a professional consultation.

With its many years of tradition and innovation, KSB offers products of the highest quality that are continuously being further developed, also in the sector of high-pressure pumps. Trust in the long tradition of our company and make use of our comprehensive service for a professional consultation.

High-pressure pumps by KSB: Reliable and durable

Thanks to many years of tradition and innovation, KSB also convinces in the field of high-pressure pumps with the highest quality, optimum performance and continuous further development. Rely on the traditional company and make use of the competent service for professional advice.

Benefits of a high-pressure pump by KSB

  • High operating reliability and a long service life ensured by corrosion-resistant hydraulic components and robust plain bearings
  • Optimised efficiencies and low operating costs with high-efficiency drive and optimised hydraulic system
  • Versatile in use and highly flexible with different material variants and a large range of connection options
  • Highest reliability: High quality and availability of pumps and service, individual service concepts and support with planning and implementing systems

Our high-pressure pumps top seller

Horizontal and vertical high-pressure pumps

Movitec

Movitec
Documents

Multistage vertical high-pressure centrifugal pump in ring-section design with suction and discharge nozzles of identical nominal diameters arranged opposite to each other (in-line design), close-coupled. With KSB SuPremE, a magnetless synchronous reluctance motor (exception: motor sizes 0.55 kW / 0.75 kW with 1500 rpm are designed with permanent magnets) of efficiency class IE4/IE5 to IEC TS 60034-30-2:2016, for operation on a KSB PumpDrive 2 or KSB PumpDrive 2 Eco variable speed system without rotor position sensors. Motor mounting points in accordance with EN 50347, envelope dimensions in accordance with DIN V 42673 (07-2011). ATEX-compliant version available.

Details

Multitec

Multitec
Documents

Multistage horizontal or vertical centrifugal pump in ring-section design, long-coupled or close-coupled, with axial or radial suction nozzle, cast radial impellers and motor-mounted variable speed system. ATEX-compliant version available.

Details

Fully automatic pressure booster systems with vertical high-pressure pumps

Ultra-high pressure pumps for heads up to 1200 m

HG

HG
Documents

Horizontal radially split ring-section pump with radial impellers, single-entry or double-entry, multistage.

Details

High-pressure pumps. Short explained.

This is how high-pressure pumps work

A high-pressure pump is a centrifugal pump with a head of approx. 200 to 1200 m and a maximum operating pressure of up to 600 bar. Pumps for larger heads and pressures are referred to as ultra-high pressure pumps.
High-pressure pumps usually serve to transport water or other fluids from a lower to a higher level. This is required for water supply systems that include the supply of high-rise buildings or suburbs at higher altitudes, for example. In this case a high-pressure pump installed in a pressure booster system can generate the necessary water pressure. With their optimised hydraulic system, the pumps also make a major contribution towards saving energy.

Strengths and applications of KSB high-pressure pumps

The applications of KSB high-pressure pumps are highly diverse. Fluids have to be pumped at increased pressure in many applications. Robust materials, an optimised hydraulic system and high-efficiency motors ensure reliable performance and a long service life of the pump.
Applications of KSB high-pressure pumps:
  • Pressure boosting
  • Industrial plants
  • General irrigation systems
  • Washing plants
  • Spray irrigation systems
  • Fire-fighting systems
  • Water supply systems
  • Heating, ventilation and air-conditioning systems
  • Marine applications
