NORI 40 FSL/FSS Strainer

StrainerNORI 40 FSL/FSS

Strainer to DIN/EN with flanged ends (FSL) or butt weld ends (FSS), made of cast steel, with standard or fine screen; all nominal sizes with drain plug in the cover, optional magnetic insert.
See all documents and downloads

Main Applications

  • Heat transfer systems
  • Process engineering
  • Chemical industry
  • Petrochemical industry

Technical Data

  • Nominal pressurePN 25, PN 40
  • Max. nominal sizeDN 300
  • Max. allowed fluid temperature450 °C

Your KSB contact: We’re here to support you

Do you need any assistance finding the right material number?
We’ll soon provide a list so you can directly place your purchase order.
Meanwhile please contact our support:

Tel: +86 4000218000


ksbpump.shanghai@ksb.com
Your KSB contact : We’re here to support you

Benefits

  • Reliable sealing. Bonnet gasket fully confined to prevent creep.
  • Long service life due to screen made of stainless steel.
  • Time and cost saving replacement of screen without removing the body insulation by using the studs as centering aids.

Technical Data

  • FunctionFilter
  • Connection typeFlange,
    Butt weld ends
  • Casing materialGP240GH+N
  • Nominal pressurePN 25,
    PN 40
  • Max. nominal sizeDN 300
  • Min. nominal sizeDN 15
  • Max. allowed fluid temperature450 °C
  • Min. allowed fluid temperature-10 °C

Sectional Drawings
