Traffic with an evening atmosphere. Solutions for the mobility of the future: carbon-neutral fuels with the help of KSB

Full throttle into the future: intelligent solutions for climate-neutral fuels

In order to limit global warming to 1.5 °C, the states that ratified the Paris Climate Agreement are committed to making climate-friendly changes to their economies, including the mobility sector. Previously, fossil fuels that produced large volumes of CO2 emissions were burned. Today, however, more sustainable solutions are in demand, with carbon-neutral, non-fossil fuels becoming increasingly important.

It's time to step up a gear – for the sake of our climate!

Technical innovation has been a strong tradition at KSB for 150 years. Developing innovative solutions is our daily work. For many years now, KSB has also been active in the area of non-fossil fuels and synthetic fuels. It knows the processes involved and can offer a whole host of state-of-the-art products.

Non-fossil fuels and synthetic fuels are gaining importance, especially in those industries in which electrification is only feasible in the long term (for example, shipping and aviation).

  • Non-fossil fuels on-fossil fuel is mostly liquid fuel produced from biomass for use in combustion engines. Renewable raw materials such as rapeseed, sugar beet, wood, straw and residues from the food processing industry can be used as basis. The most important types of non-fossil fuels are biodiesel, bioethanol, biomethane and vegetable oil (rapeseed oil).

  • Synthetic fuels or synfuels are produced from a mixture of isolated carbon dioxide and climate-neutral hydrogen. These fuels are currently in the development phase. However, they will play a major role in the future, especially in industries that are not easily electrified

Whether you are a consultant, licensor, engineering contractor or operator, you need a partner who is familiar with this topic and understands your needs. KSB has both the necessary expertise and the right products for you:

  • Pumps used in fermentation and transesterification processes operate under the toughest conditions. Thanks to their large range of seal and material variants, our MegaCPK and Magnochem standardised chemical pump series are particularly suitable for aggressive fluids. In process steps involving solids-laden fluids, our KWP series impresses with its wear-resistant design and impeller variance.

  • In secondary processes, our ETA series pumps ensure reliable and efficient water transport. KSB’s Movitec, Multitec and HG series provide the necessary water pressure through their multistage design.

In addition to our extensive pump range, we also supply valves that are suitable for a variety of process fluids and supply fluids. These include manual, actuated and controlled valves as well as those equipped with positioners:

  • The ISORIA butterfly valve is an all-rounder. With over three million standard variants, this valve is extremely versatile.

  • The double-offset DANAIS butterfly valve can also easily handle high temperatures.

  • The KE butterfly valves and the SISTO diaphragm valves are the right solutions for aggressive fluids or special requirements relating to emissions control.

As a full-range supplier, we are able to equip entire systems with the necessary pumps, valves and automation solutions. We provide products to the API and ISO standards, including mag-drive pumps, suitable mechanical seals, and lots more. Moreover, an ATEX-compliant version of our intelligent monitoring solution, KSB Guard, is available to facilitate smart monitoring of systems.

Thanks to our technical excellence and passion for innovative solutions in the area of eco-friendly technologies, we are making an important contribution towards greater sustainability and therefore a better future. Welcome to the world of green solutions!

Service on slurry pump

Our non-fossil fuels services

Successfully operating your pump systems requires more than excellent products: We also invite you to benefit from our broad service portfolio covering planning, operation and maintenance of valves, pumps and other rotating equipment. We are there for you, with more than 3500 specialists in over 190 service centres around the globe.

Our non-fossil fuel products

KSB is a full-range supplier for pumps, valves and service with decades of experience and in-depth application knowledge. All KSB products offer long-term efficiency as well as reliability and require minimal maintenance, thus ensuring the economic, trouble-free operation of your systems.

MegaCPK

MegaCPK

Horizontal radially split volute casing pump in back pull-out design, with radial impeller, single-entry, single-stage, to DIN EN ISO 5199, dimensions to DIN EN ISO 2858, complemented by nominal diameters DN25 and ≥DN200, in large range of material and seal variants; also available as a variant with "wet" shaft and conical seal chamber. ATEX-compliant version available.

Magnochem

Magnochem

Horizontal seal-less volute casing pump in back pull-out design, with magnetic drive, to DIN EN ISO 2858 / ISO 5199, with radial impeller, single-entry, single-stage. ATEX-compliant version available.

CPKN

CPKN

Horizontal radially split volute casing pump in back pull-out design, with radial impeller, single-entry, single-stage, to ISO 2858 / ISO 5199. Also available as a variant with "wet" shaft, conical seal chamber and/or semi-open impeller. ATEX-compliant version available.

RPHb/RPHd/RPHbd

RPHb/RPHd/RPHbd

Heavy-duty horizontal radially split between-bearings volute casing pump to API 610, ISO 13709 (heavy duty), type BB2, with radial impellers, single- or double-entry, single- or two-stage design with centreline pump feet. ATEX-compliant version available.

ISORIA 10/16

ISORIA 10/16

Centred-disc butterfly valve with ISO 5211 compliant square shaft end, sealed by elastomer liner, with lever or manual gearbox, pneumatic, electric or hydraulic actuator. Wafer-type body (T1), semi-lug body (T2), full-lug body (T4) or U-section body with flat faces (T5). Body types T2 and T4 are suitable for downstream dismantling and dead-end service with counterflange. Connections to EN, ASME, JIS.

DANAÏS 150

DANAÏS 150

Double-offset butterfly valve with ISO 5211 compliant square shaft end, with plastomer seat (also in fire-safe design), metal seat or elastomer seat (FKM [VITON R] or NBR [nitrile]). Lever or manual gearbox, pneumatic, electric or hydraulic actuator. Body made of nodular cast iron, cast steel, stainless steel or duplex stainless steel (254 SMO). Wafer-type body (T1), full-lug body (T4), T4 suitable for downstream dismantling and dead-end service with counterflange. Connections to EN, ASME or JIS. Fire-safe design tested and certified to API 607. Fugitive emissions performance tested and certified to EN ISO 15848-1. ATEX-compliant version in accordance with Directive 2014/34/EU.

KE

KE

Centred-disc butterfly valve with ISO 5211 compliant square shaft end and PFA liner. With lever, manual gearbox, pneumatic or electric actuator. With wafer-type body (T1), full-lug body (T4) or U-section body with raised faces (T6). EN, ASME, JIS connections possible.

SISTO-20

SISTO-20

Weir-type diaphragm valve to DIN/EN with flanged ends, threaded socket ends or socket weld ends, in straight-way pattern; shut-off and sealing to atmosphere by supported and confined diaphragm; body with coating or lining, position indicator with integrated stem protection. All moving parts are separated from the fluid by the diaphragm. Maintenance-free.
